Site ROM9

ROM9

ROMA (sede INGV), Roma

  • Id: 269
  • Spatial Reference System: GCS_WGS_1984
  • Latitude [°]: 41.82869
  • Longitude [°]: 12.51553
  • Elevation [m]: 50
  • StartTime: 01/03/2003 00:00:00
  • EndTime:
  • Type: PERMANENT
  • Description: ROMA (sede INGV), Roma
  • Site Name: ROM9
  • Station Name: IV.ROM9
  • Sensors: KINEMETRICS EPISENSOR (m/s**2)
  • Q Final:
  • Allegato:
  • Note:

Map Layers

Housing

Instrument Housing
Picture Sensor Picture Site Picture Panorama Coupling Insulating Housing Note Noise source
Img Img Img PILLAR ABSENT BOX The station is in the garden of INGV Headquarter in Rome. From Sept 2015, only accelerometer is present 8
Data Quality
Component Band Instrument Seasonal noise figure Annual noise figure Data Quality Values
E HH Img Img 101
N HH Img Img 101
Z HH Img Img 101

Geology

Stratigraphy
Site name Reference System Latitude [°] Longitude [°] Drilling ID Depth [m] Elevation [m] Source Site Distance [m] Drilling Date
ROM9 GCS_WGS_1984 41.8287 12.5148 75 50 geognostic survey 20
Geological Review
Preferred Bibliography Monography Conceptual Model Value
Yes BONOMO R., D’AMBROGI C., D’OREFICE M., FIORENZA D., GAFÀ R. M. MONTI G.M., Di MANNA M., ROMA M., VITA L., Final Report Development of a conceptual geological model for five seismic station with accelerometer of the INGV Seismic Network, Internal Report ISPRA-INGV (2017)
download 0
No Monti G. M., Martarelli L., Gafà R. M., Olivetta L., Caratterizzazione geolitologica dei siti su cui ricadono le stazioni della Rete Sismica Nazionale dell’INGV, INGV- ISPRA 2016-17 Agreement (protocol INGV 2016/0003777 of 04/04/2016): "Scientific and technical collaboration aimed at the geolithological characterization of the sites of the stations of the national INGV seismic network "(Scientific Coordinators: P. Bordoni and G.M. Monti) (2016)
download 5
Morphological classification
Preferred Type Note Dem Resolution [m] Slope Range Slope [°] Slope Range Figure
No RELIEF 30.00000 ANGLE_LE15 2.33000 Img
Yes RELIEF 10.00000 ANGLE_LE15 1.32000 Img
Lithological Classification
Preferred Cartography Code Coding Type Lithological Unit Code Volumetric Joint Count Consolidation Degree Lithologic Class Lithologic Description Number Of Lithology Subdivision
Yes Foglio Carta Litologica d’Italia 1:100,000 - Foglio ROMA ISPRA 2010 D5 consolidation_variable Pyroclastic material (pyroclast, tuff, ignimbrite) piroclastiti , tufi, ignimbriti 3
Geological Classification
Preferred Cartography code Coding type Geological unit extended name Environmental settings Age (Older - Younger) Rock mass structure Event Process
Yes Foglio Carta Geolitologica d'Italia 1:100,000 - Foglio ROMA INSPIRE pozzolane superiori terrestrial_setting Pleistocene - Pleistocene compositional_layering pyroclastic_eruption
Fault Classification
No Data Available
Landslide Classification
No Data Available
Cross Section
Cartography Geological
Cross Section 		Latitude 1 [°] Longitude 1 [°] Latitude 2 [°] Longitude 2 [°] Spatial Ref Sys
Foglio ROMA - Carta Geologica d’Italia 1:100,000 Img 41.82466 12.51244 41.83377 12.51984 GCS_WGS_1984

Seismology

HVEQ
No Data Available
HVNoise
Preferred Start time End time Noise variability types Frequency range min [Hz] Frequency range max [Hz] Band Instrument Picture of rotated ratio Picture of ratio Number of peaks
No 10/03/2017 10:00:00 10/03/2017 12:00:00 DAYTIME 0.2 20 EH Img Img 1
No 09/03/2017 11:00:00 09/03/2017 13:00:00 DAYTIME 0.2 20 EH Img Img 1
Yes 19/08/2015 22:59:58 20/08/2015 22:59:59 DAYTIME 0.1 15 HH Img Img 0
SSREQ
No Data Available
Signal Polarization
No Data Available

Geophysics

Subsoil Model
Id Type Investigation Pref. Latitude [°] Longitude [°] Elevation [m] Figure Monography
5 NON_LINEAR_CURVE RC YES 41.828419 12.51553 50 Img Img
21 VELOCITY_PROFILE DH NO 41.828419 12.51553 50 Img Img
3 VELOCITY_PROFILE SA NO 41.828419 12.51553 50 Img Img
28 VELOCITY_PROFILE CH NO 41.828419 12.51553 50 Img Img
53 VELOCITY_PROFILE COMPOUND YES 41.828419 12.51553 50 Img

Site classification

Topography Class
Topography Class Type Topography Class Value Topography Class Preferred Topography Class Note Seismic Code Type Bibliography Last Update
DEM T1 No Slope: 1.53°, Vs30: 396 m/s NTC18 C. Mascandola, L. Luzi, C. Felicetta and F. Pacor, A GIS procedure for the topographic classification of Italy, according to the seismic code provisions, Soil Dynamics and Earthquake Engineering, (2021)
2024-02-22 17:16:15
OTHER T1 No googlEarth_10m EC8 2022-02-09 21:38:33
DEM T1 No dem_10m EC8 V. Pessina and E. Fiorini, A GIS procedure for fast topographic characterization of seismic recording stations, Soil Dynamics and Earthquake Engineering, (2014)
2024-02-22 17:16:15
DEM T1 No dem_30m EC8 V. Pessina and E. Fiorini, A GIS procedure for fast topographic characterization of seismic recording stations, Soil Dynamics and Earthquake Engineering, (2014)
2022-02-09 21:39:15
OTHER T1 No GoogleEarth EC8 2022-02-09 21:40:55
Site Class
Soil Class Type Soil Class Value Soil Class Preferred Soil Class Note Seismic Code Type Bibliography Last Update
GEOLOGY C No Obtained by dataset (ASCII file GR ID) https://data.mendeley.com/datasets/8458tgzc73/1 EC8 Mori F., Mendicelli A., Moscatelli M., Romagnoli G., Peronace E., Naso G., A new Vs30 map for Italy based on the seismic microzonation dataset, Engineering Geology, (2020)
2023-05-18 08:26:15
GEOLOGY C No Obtained by Standalone Software SSC-Italy http://wpage.unina.it/iuniervo/SSC-Italy.zip NTC18 Forte G., Chioccarelli E., De Falco M., Cito P., Santo A., Iervolino I., Seismic soil classification of Italy based on surface geology and shear-wave velocity measurements, Soil Dynamics and Earthquake Engineering, (2019)
2023-05-18 08:25:56
GEOLOGY C No Obtained by Standalone Software SSC-Italy http://wpage.unina.it/iuniervo/SSC-Italy.zip EC8 Forte G., Chioccarelli E., De Falco M., Cito P., Santo A., Iervolino I., Seismic soil classification of Italy based on surface geology and shear-wave velocity measurements, Soil Dynamics and Earthquake Engineering, (2019)
2023-05-18 08:25:18
DOWNHOLE B Yes Vs30=532 m/s downhole. For details see VELOCITY_PROFILE=DH in Geophysics section EC8 Cercato M, Desideri F.S., Pugliese F., Risultati delle prove geofisiche in foro di tipo Down-Hole (DH) Sede INGV - Via di Vigna Murata 605 (RM), DICEA- Univ. La Sapienza (Agreement DPCINGV 2018, All. B2: Obiettivo 1 - TASKB) (2018)
2022-02-15 09:47:54
DOWNHOLE B Yes Vseq=532 m/s derived from downhole. For details see VELOCITY_PROFILE=DH in Geophysics section NTC18 Cercato M, Desideri F.S., Pugliese F., Risultati delle prove geofisiche in foro di tipo Down-Hole (DH) Sede INGV - Via di Vigna Murata 605 (RM), DICEA- Univ. La Sapienza (Agreement DPCINGV 2018, All. B2: Obiettivo 1 - TASKB) (2018)
2022-02-15 09:47:54
GEOLOGY B No from di Capua et al. 2016 EC8 Di Capua G., Peppoloni S., Amanti M., Cipolloni C., Conte G., Site classification map of Italy based on surface geology, Geological Society, London, Engineering Geology Special Publications, (2016)
2022-02-15 09:47:55
CROSSHOLE B No vs30=605 m/s crosshole. For details see VELOCITY_PROFILE=CH in Geophysics section EC8 Cercato M., Desideri F.S., Pugliese F., Risultati delle prove geofisiche in foro di tipo Cross-Hole (CH) Sede INGV - Via di Vigna Murata 605 (RM), DICEA- Univ. La Sapienza (Agreement DPCINGV 2018, All. B2: Obiettivo 1 - TASKB) (2018)
2023-05-29 08:28:16
ARRAY_MEASUREMENT B No Vs30=410 m/s passive array measurements. For details see VELOCITY_PROFILE=SA in Geophysics section EC8 Di Giulio G., Vassallo M., Bordoni P., Cultrera G.,, Milano G., Amoroso S., Famiani D., Cara F., Carlucci G., Attolico D., Site characterization of the INGV station IV.ROM9 – ROMA (INGV garden), Working group INGV of DPC-INGV 2016 agreement All. B2 Task B (2016)
2023-05-29 08:28:17
